TEA1522P/N2,112 Images
- Manufacturer: NXP
- Category: Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers Package/Case: 8-DIP (0.300, 7.62mm)
- Description: IC OFFLINE SWITCH FLYBACK 8DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TEA1522P/N2,112 Specifications:
- MfrPart.: TEA1522P/N2,112
- Mfr: NXP USA Inc.
- Description: IC OFFLINE SWITCH FLYBACK 8DIP
- Product Category: Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers
- Package: Tube
- Series: STARplug™
- PartStatus: Obsolete
- OutputIsolation: Isolated
- InternalSwitch(s): Yes
- Voltage-Breakdown: 650V
- Topology: Flyback
- Voltage-StartUp: 9.5 V
- Voltage-Supply(Vcc/Vdd): 7.5V ~ 40V
- DutyCycle: 75%
- Frequency-Switching: 10kHz ~ 200kHz
- Power(Watts): 30 W
- FaultProtection: Current Limiting, Over Temperature, Short Circuit
- ControlFeatures: Frequency Control
- OperatingTemperature: -40°C ~ 145°C (TJ)
- Package/Case: 8-DIP (0.300, 7.62mm)
- TEA1522P/N2,112 NXP, IC OFFLINE SWITCH FLYBACK 8DIP, Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers
