S9S12GN16BMTJ NXP IC MCU 16BIT 16KB FLASH 20TSSOP
S9S12GN16BMTJ Images
S9S12GN16BMTJ Images
  • Manufacturer: NXP
  • Category: Integrated Circuits (ICs)~Embedded - Microcontrollers Package/Case: 20-TSSOP (0.173, 4.40mm Width)
  • Description: IC MCU 16BIT 16KB FLASH 20TSSOP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
S9S12GN16BMTJ Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
S9S12GN16BMTJ Specifications:
  • MfrPart.: S9S12GN16BMTJ
  • Mfr: NXP USA Inc.
  • Description: IC MCU 16BIT 16KB FLASH 20TSSOP
  • Product Category: Integrated Circuits (ICs)~Embedded - Microcontrollers
  • Package: Tube
  • Series: HCS12
  • PartStatus: Active
  • CoreProcessor: CPU12V1
  • CoreSize: 16-Bit
  • Speed: 25MHz
  • Connectivity: IrDA, LINbus, SCI, SPI
  • Peripherals: LVD, POR, PWM, WDT
  • NumberofI/O: 14
  • ProgramMemorySize: 16KB (16K x 8)
  • ProgramMemoryType: FLASH
  • EEPROMSize: 512 x 8
  • RAMSize: 1K x 8
  • Voltage-Supply(Vcc/Vdd): 3.13V ~ 5.5V
  • DataConverters: A/D 8x10b
  • OscillatorType: Internal
  • OperatingTemperature: -40°C ~ 125°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 20-TSSOP (0.173, 4.40mm Width)
  • S9S12GN16BMTJ NXP, IC MCU 16BIT 16KB FLASH 20TSSOP, Integrated Circuits (ICs)~Embedded - Microcontrollers
S9S12GN16BMTJ, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
