PTN36502HQX NXP IC REDRIVER USB 3.1 & DP 1.2 QFN
PTN36502HQX Images
PTN36502HQX Images
  • Manufacturer: NXP
  • Category: Integrated Circuits (ICs)~Interface - Signal Buffers, Repeaters, Splitters Package/Case: 24-XFQFN Exposed Pad
  • Description: IC REDRIVER USB 3.1 & DP 1.2 QFN
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
PTN36502HQX Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
PTN36502HQX Specifications:
  • MfrPart.: PTN36502HQX
  • Mfr: NXP USA Inc.
  • Description: IC REDRIVER USB 3.1 & DP 1.2 QFN
  • Product Category: Integrated Circuits (ICs)~Interface - Signal Buffers, Repeaters, Splitters
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • PartStatus: Active
  • Type: Buffer, ReDriver
  • Applications: USB Type C
  • Input: Differential
  • Output: Differential
  • DataRate(Max): 5.4Gbps
  • NumberofChannels: -
  • DelayTime: 140ps
  • SignalConditioning: Input Equalization, Output De-Emphasis
  • Capacitance-Input: -
  • Voltage-Supply: 1.7V ~ 1.9V
  • Current-Supply: 225mA
  • OperatingTemperature: -40°C ~ 85°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 24-XFQFN Exposed Pad
  • PTN36502HQX NXP, IC REDRIVER USB 3.1 & DP 1.2 QFN, Integrated Circuits (ICs)~Interface - Signal Buffers, Repeaters, Splitters
PTN36502HQX, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
