PSMN9R0-30YL,115 NXP MOSFET N-CH 30V 61A LFPAK56
PSMN9R0-30YL,115 Images
PSMN9R0-30YL,115 Images
  • Manufacturer: NXP
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: LFPAK56, Power-SO8
  • Description: MOSFET N-CH 30V 61A LFPAK56
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
PSMN9R0-30YL,115 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
PSMN9R0-30YL,115 Specifications:
  • MfrPart.: PSMN9R0-30YL,115
  • Mfr: NXP USA Inc.
  • Description: MOSFET N-CH 30V 61A LFPAK56
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Bulk
  • Series: -
  • PartStatus: Obsolete
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 30 V
  • Current-ContinuousDrain(Id)@25°C: 61A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
  • RdsOn(Max)@IdVgs: 8mOhm @ 15A, 10V
  • Vgs(th)(Max)@Id: 2.15V @ 1mA
  • GateCharge(Qg)(Max)@Vgs: 17.8 nC @ 10 V
  • Vgs(Max): ±20V
  • InputCapacitance(Ciss)(Max)@Vds: 1.006 pF @ 12 V
  • FETFeature: -
  • PowerDissipation(Max): 46W (Tc)
  • OperatingTemperature: -55°C ~ 175°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: LFPAK56, Power-SO8
  • PSMN9R0-30YL,115 NXP, MOSFET N-CH 30V 61A LFPAK56, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
PSMN9R0-30YL,115, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
