PSMN012-25YLC,115 Images
- Manufacturer: NXP
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: LFPAK56, Power-SO8
- Description: MOSFET N-CH 25V 33A LFPAK56
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PSMN012-25YLC,115 Specifications:
- MfrPart.: PSMN012-25YLC,115
- Mfr: NXP USA Inc.
- Description: MOSFET N-CH 25V 33A LFPAK56
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 25 V
- Current-ContinuousDrain(Id)@25°C: 33A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 12.6mOhm @ 10A, 10V
- Vgs(th)(Max)@Id: 1.95V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 8.3 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 528 pF @ 12 V
- FETFeature: -
- PowerDissipation(Max): 26W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: LFPAK56, Power-SO8
- PSMN012-25YLC,115 NXP, MOSFET N-CH 25V 33A LFPAK56, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
