PMV60EN,215 Images
- Manufacturer: NXP
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-23 (TO-236AB)
- Description: MOSFET N-CH 30V 4.7A TO236AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PMV60EN,215 Specifications:
- MfrPart.: PMV60EN,215
- Mfr: NXP USA Inc.
- Description: MOSFET N-CH 30V 4.7A TO236AB
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: TrenchMOS™
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 4.7A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 55mOhm @ 2A, 10V
- Vgs(th)(Max)@Id: 2V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 9.4 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 350 pF @ 30 V
- FETFeature: -
- PowerDissipation(Max): 280mW (Tj)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-23 (TO-236AB)
- PMV60EN,215 NXP, MOSFET N-CH 30V 4.7A TO236AB, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
PMV60EN,215, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
