PMT21EN,135 NXP MOSFET N-CH 30V 7.4A SOT223
PMT21EN,135 Images
PMT21EN,135 Images
  • Manufacturer: NXP
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SC-73
  • Description: MOSFET N-CH 30V 7.4A SOT223
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
PMT21EN,135 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
PMT21EN,135 Specifications:
  • MfrPart.: PMT21EN,135
  • Mfr: NXP USA Inc.
  • Description: MOSFET N-CH 30V 7.4A SOT223
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • PartStatus: Obsolete
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 30 V
  • Current-ContinuousDrain(Id)@25°C: 7.4A (Ta)
  • DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
  • RdsOn(Max)@IdVgs: 21mOhm @ 7.4A, 10V
  • Vgs(th)(Max)@Id: 2.5V @ 250µA
  • GateCharge(Qg)(Max)@Vgs: 14.4 nC @ 10 V
  • Vgs(Max): ±20V
  • InputCapacitance(Ciss)(Max)@Vds: 588 pF @ 15 V
  • FETFeature: -
  • PowerDissipation(Max): 820mW (Ta), 8.33W (Tc)
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: SC-73
  • PMT21EN,135 NXP, MOSFET N-CH 30V 7.4A SOT223, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
PMT21EN,135, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
