PMN49EN,165 NXP MOSFET N-CH 30V 4.6A 6TSOP
PMN49EN,165 Images
PMN49EN,165 Images
  • Manufacturer: NXP
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SC-74
  • Description: MOSFET N-CH 30V 4.6A 6TSOP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
PMN49EN,165 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
PMN49EN,165 Specifications:
  • MfrPart.: PMN49EN,165
  • Mfr: NXP USA Inc.
  • Description: MOSFET N-CH 30V 4.6A 6TSOP
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tape & Reel (TR)
  • Series: TrenchMOS™
  • PartStatus: Obsolete
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 30 V
  • Current-ContinuousDrain(Id)@25°C: 4.6A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
  • RdsOn(Max)@IdVgs: 47mOhm @ 2A, 10V
  • Vgs(th)(Max)@Id: 2V @ 1mA
  • GateCharge(Qg)(Max)@Vgs: 8.8 nC @ 4.5 V
  • Vgs(Max): ±20V
  • InputCapacitance(Ciss)(Max)@Vds: 350 pF @ 30 V
  • FETFeature: -
  • PowerDissipation(Max): 1.75W (Tc)
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: SC-74
  • PMN49EN,165 NXP, MOSFET N-CH 30V 4.6A 6TSOP, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
PMN49EN,165, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
