PHT2NQ10T,135 Images
- Manufacturer: NXP
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SC-73
- Description: MOSFET N-CH 100V 2.5A SOT223
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PHT2NQ10T,135 Specifications:
- MfrPart.: PHT2NQ10T,135
- Mfr: NXP USA Inc.
- Description: MOSFET N-CH 100V 2.5A SOT223
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: TrenchMOS™
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 2.5A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 430mOhm @ 1.75A, 10V
- Vgs(th)(Max)@Id: 4V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 5.1 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 160 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 6.25W (Tc)
- OperatingTemperature: -65°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SC-73
- PHT2NQ10T,135 NXP, MOSFET N-CH 100V 2.5A SOT223, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
PHT2NQ10T,135, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
