PHD55N03LTA,118 Images
- Manufacturer: NXP
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
- Description: MOSFET N-CH 25V 55A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PHD55N03LTA,118 Specifications:
- MfrPart.: PHD55N03LTA,118
- Mfr: NXP USA Inc.
- Description: MOSFET N-CH 25V 55A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: TrenchMOS™
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 25 V
- Current-ContinuousDrain(Id)@25°C: 55A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 5V, 10V
- RdsOn(Max)@IdVgs: 14mOhm @ 25A, 10V
- Vgs(th)(Max)@Id: 2V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 20 nC @ 5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 950 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 85W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK
- PHD55N03LTA,118 NXP, MOSFET N-CH 25V 55A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
PHD55N03LTA,118, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
