PHB225NQ04T,118 NXP MOSFET N-CH 40V 75A D2PAK
PHB225NQ04T,118 Images
PHB225NQ04T,118 Images
  • Manufacturer: NXP
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D2PAK
  • Description: MOSFET N-CH 40V 75A D2PAK
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
PHB225NQ04T,118 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
PHB225NQ04T,118 Specifications:
  • MfrPart.: PHB225NQ04T,118
  • Mfr: NXP USA Inc.
  • Description: MOSFET N-CH 40V 75A D2PAK
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tape & Reel (TR)
  • Series: TrenchMOS™
  • PartStatus: Obsolete
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 40 V
  • Current-ContinuousDrain(Id)@25°C: 75A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 10V
  • RdsOn(Max)@IdVgs: 3.1mOhm @ 25A, 10V
  • Vgs(th)(Max)@Id: 4V @ 1mA
  • GateCharge(Qg)(Max)@Vgs: 94 nC @ 10 V
  • Vgs(Max): ±20V
  • InputCapacitance(Ciss)(Max)@Vds: 5100 pF @ 25 V
  • FETFeature: -
  • PowerDissipation(Max): 300W (Tc)
  • OperatingTemperature: -55°C ~ 175°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: D2PAK
  • PHB225NQ04T,118 NXP, MOSFET N-CH 40V 75A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
PHB225NQ04T,118, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
