PHB222NQ04LT,118 Images
- Manufacturer: NXP
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D2PAK
- Description: MOSFET N-CH 40V 75A D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PHB222NQ04LT,118 Specifications:
- MfrPart.: PHB222NQ04LT,118
- Mfr: NXP USA Inc.
- Description: MOSFET N-CH 40V 75A D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: TrenchMOS™
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 75A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 2.8mOhm @ 25A, 10V
- Vgs(th)(Max)@Id: 2V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 93.6 nC @ 5 V
- Vgs(Max): ±15V
- InputCapacitance(Ciss)(Max)@Vds: 7880 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 300W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D2PAK
- PHB222NQ04LT,118 NXP, MOSFET N-CH 40V 75A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
PHB222NQ04LT,118, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
