PHB20N06T,118 NXP MOSFET N-CH 55V 20.3A D2PAK
PHB20N06T,118 Images
PHB20N06T,118 Images
  • Manufacturer: NXP
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D2PAK
  • Description: MOSFET N-CH 55V 20.3A D2PAK
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
PHB20N06T,118 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
PHB20N06T,118 Specifications:
  • MfrPart.: PHB20N06T,118
  • Mfr: NXP USA Inc.
  • Description: MOSFET N-CH 55V 20.3A D2PAK
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Bulk
  • Series: TrenchMOS™
  • PartStatus: Active
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 55 V
  • Current-ContinuousDrain(Id)@25°C: 20.3A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 10V
  • RdsOn(Max)@IdVgs: 75mOhm @ 10A, 10V
  • Vgs(th)(Max)@Id: 4V @ 1mA
  • GateCharge(Qg)(Max)@Vgs: 11 nC @ 10 V
  • Vgs(Max): ±20V
  • InputCapacitance(Ciss)(Max)@Vds: 483 pF @ 25 V
  • FETFeature: -
  • PowerDissipation(Max): 62W (Tc)
  • OperatingTemperature: -55°C ~ 175°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: D2PAK
  • PHB20N06T,118 NXP, MOSFET N-CH 55V 20.3A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
PHB20N06T,118, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
