PH1825AL,115 NXP MOSFET N-CH 25V 100A LFPAK56
PH1825AL,115 Images
PH1825AL,115 Images
  • Manufacturer: NXP
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: LFPAK56, Power-SO8
  • Description: MOSFET N-CH 25V 100A LFPAK56
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
PH1825AL,115 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
PH1825AL,115 Specifications:
  • MfrPart.: PH1825AL,115
  • Mfr: NXP USA Inc.
  • Description: MOSFET N-CH 25V 100A LFPAK56
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tape & Reel (TR)
  • Series: TrenchMOS™
  • PartStatus: Obsolete
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 25 V
  • Current-ContinuousDrain(Id)@25°C: 100A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
  • RdsOn(Max)@IdVgs: 1.8mOhm @ 25A, 10V
  • Vgs(th)(Max)@Id: 2.15V @ 1mA
  • GateCharge(Qg)(Max)@Vgs: 31 nC @ 4.5 V
  • Vgs(Max): ±20V
  • InputCapacitance(Ciss)(Max)@Vds: 4300 pF @ 12 V
  • FETFeature: -
  • PowerDissipation(Max): 104W (Tc)
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: LFPAK56, Power-SO8
  • PH1825AL,115 NXP, MOSFET N-CH 25V 100A LFPAK56, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
PH1825AL,115, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
