PDTC114EMB,315 NXP PDTC114EMB - UPN RESISTOR-EQUIPP
PDTC114EMB,315 Images
PDTC114EMB,315 Images
  • Manufacturer: NXP
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single, Pre-Biased Package/Case: 3-XFDFN
  • Description: PDTC114EMB - UPN RESISTOR-EQUIPP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
PDTC114EMB,315 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
PDTC114EMB,315 Specifications:
  • MfrPart.: PDTC114EMB,315
  • Mfr: NXP Semiconductors
  • Description: PDTC114EMB - UPN RESISTOR-EQUIPP
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single, Pre-Biased
  • Package: Bulk
  • Series: -
  • PartStatus: Active
  • TransistorType: NPN - Pre-Biased
  • Current-Collector(Ic)(Max): 100 mA
  • Voltage-CollectorEmitterBreakdown(Max): 50 V
  • Resistor-Base(R1): 10 kOhms
  • Resistor-EmitterBase(R2): 10 kOhms
  • DCCurrentGain(hFE)(Min)@IcVce: 30 @ 5mA, 5V
  • VceSaturation(Max)@IbIc: 150mV @ 500µA, 10mA
  • Current-CollectorCutoff(Max): 1µA
  • Frequency-Transition: 230 MHz
  • Power-Max: 250 mW
  • MountingType: Surface Mount
  • Package/Case: 3-XFDFN
  • PDTC114EMB,315 NXP, PDTC114EMB - UPN RESISTOR-EQUIPP, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single, Pre-Biased
PDTC114EMB,315, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
