PDTA114ET,235 NXP NOW NEXPERIA PDTA114 - SMALL SIG
PDTA114ET,235 Images
PDTA114ET,235 Images
  • Manufacturer: NXP
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single, Pre-Biased Package/Case: TO-236-3, SC-59, SOT-23-3
  • Description: NOW NEXPERIA PDTA114 - SMALL SIG
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
PDTA114ET,235 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
PDTA114ET,235 Specifications:
  • MfrPart.: PDTA114ET,235
  • Mfr: NXP USA Inc.
  • Description: NOW NEXPERIA PDTA114 - SMALL SIG
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single, Pre-Biased
  • Package: Bulk
  • Series: -
  • PartStatus: Active
  • TransistorType: PNP - Pre-Biased
  • Current-Collector(Ic)(Max): 100 mA
  • Voltage-CollectorEmitterBreakdown(Max): 50 V
  • Resistor-Base(R1): 10 kOhms
  • Resistor-EmitterBase(R2): 10 kOhms
  • DCCurrentGain(hFE)(Min)@IcVce: 30 @ 5mA, 5V
  • VceSaturation(Max)@IbIc: 150mV @ 500µA, 10mA
  • Current-CollectorCutoff(Max): 1µA
  • Frequency-Transition: -
  • Power-Max: 250 mW
  • MountingType: Surface Mount
  • Package/Case: TO-236-3, SC-59, SOT-23-3
  • PDTA114ET,235 NXP, NOW NEXPERIA PDTA114 - SMALL SIG, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single, Pre-Biased
PDTA114ET,235, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
