PBLS4003D,115 NXP NOW NEXPERIA PBLS4003D - SMALL S
PBLS4003D,115 Images
PBLS4003D,115 Images
  • Manufacturer: NXP
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased Package/Case: SC-74, SOT-457
  • Description: NOW NEXPERIA PBLS4003D - SMALL S
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
PBLS4003D,115 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
PBLS4003D,115 Specifications:
  • MfrPart.: PBLS4003D,115
  • Mfr: NXP USA Inc.
  • Description: NOW NEXPERIA PBLS4003D - SMALL S
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased
  • Package: Bulk
  • Series: -
  • PartStatus: Active
  • TransistorType: 1 NPN Pre-Biased, 1 PNP
  • Current-Collector(Ic)(Max): 100mA, 700mA
  • Voltage-CollectorEmitterBreakdown(Max): 50V, 40V
  • Resistor-Base(R1): 10kOhms
  • Resistor-EmitterBase(R2): 10kOhms
  • DCCurrentGain(hFE)(Min)@IcVce: 30 @ 5mA, 5V / 300 @ 100mA, 5V
  • VceSaturation(Max)@IbIc: 150mV @ 500µA, 10mA / 310mV @ 100mA, 1A
  • Current-CollectorCutoff(Max): 1µA, 100nA
  • Frequency-Transition: 150MHz
  • Power-Max: 600mW
  • MountingType: Surface Mount
  • Package/Case: SC-74, SOT-457
  • PBLS4003D,115 NXP, NOW NEXPERIA PBLS4003D - SMALL S, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased
PBLS4003D,115, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
