PBLS1504Y,115 NXP PBLS1504Y - 15 V PNP BISS LOADSW
PBLS1504Y,115 Images
PBLS1504Y,115 Images
  • Manufacturer: NXP
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased Package/Case: 6-TSSOP, SC-88, SOT-363
  • Description: PBLS1504Y - 15 V PNP BISS LOADSW
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
PBLS1504Y,115 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
PBLS1504Y,115 Specifications:
  • MfrPart.: PBLS1504Y,115
  • Mfr: NXP USA Inc.
  • Description: PBLS1504Y - 15 V PNP BISS LOADSW
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased
  • Package: Bulk
  • Series: -
  • PartStatus: Active
  • TransistorType: 1 NPN Pre-Biased, 1 PNP
  • Current-Collector(Ic)(Max): 100mA, 500mA
  • Voltage-CollectorEmitterBreakdown(Max): 50V, 15V
  • Resistor-Base(R1): 22kOhms
  • Resistor-EmitterBase(R2): 22kOhms
  • DCCurrentGain(hFE)(Min)@IcVce: 60 @ 5mA, 5V / 150 @ 100mA, 2V
  • VceSaturation(Max)@IbIc: 150mV @ 500µA, 10mA / 250mV @ 50mA, 500mA
  • Current-CollectorCutoff(Max): 1µA, 100nA
  • Frequency-Transition: 280MHz
  • Power-Max: 300mW
  • MountingType: Surface Mount
  • Package/Case: 6-TSSOP, SC-88, SOT-363
  • PBLS1504Y,115 NXP, PBLS1504Y - 15 V PNP BISS LOADSW, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased
PBLS1504Y,115, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
