MC9S08DZ16CLF NXP IC MCU 8BIT 16KB FLASH 48LQFP
MC9S08DZ16CLF Images
MC9S08DZ16CLF Images
MC9S08DZ16CLF
  • Manufacturer: NXP
  • Category: Integrated Circuits (ICs)~Embedded - Microcontrollers Package/Case: 48-LQFP
  • Description: IC MCU 8BIT 16KB FLASH 48LQFP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
MC9S08DZ16CLF Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
MC9S08DZ16CLF Specifications:
  • MfrPart.: MC9S08DZ16CLF
  • Mfr: NXP USA Inc.
  • Description: IC MCU 8BIT 16KB FLASH 48LQFP
  • Product Category: Integrated Circuits (ICs)~Embedded - Microcontrollers
  • Package: Tray
  • Series: S08
  • PartStatus: Obsolete
  • CoreProcessor: S08
  • CoreSize: 8-Bit
  • Speed: 40MHz
  • Connectivity: CANbus, I²C, LINbus, SCI, SPI
  • Peripherals: LVD, POR, PWM, WDT
  • NumberofI/O: 39
  • ProgramMemorySize: 16KB (16K x 8)
  • ProgramMemoryType: FLASH
  • EEPROMSize: 512 x 8
  • RAMSize: 1K x 8
  • Voltage-Supply(Vcc/Vdd): 2.7V ~ 5.5V
  • DataConverters: A/D 16x12b
  • OscillatorType: External
  • OperatingTemperature: -40°C ~ 85°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 48-LQFP
  • MC9S08DZ16CLF NXP, IC MCU 8BIT 16KB FLASH 48LQFP, Integrated Circuits (ICs)~Embedded - Microcontrollers
