MC33696FJAER2 Images
- Manufacturer: NXP
- Category: RF-IF and RFID~RF Transceiver ICs Package/Case: 32-VFQFN Exposed Pad
- Description: IC RF TXRX ISM<1GHZ 32VFQFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MC33696FJAER2 Specifications:
- MfrPart.: MC33696FJAER2
- Mfr: NXP USA Inc.
- Description: IC RF TXRX ISM<1GHZ 32VFQFN
- Product Category: RF-IF and RFID~RF Transceiver ICs
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- Type: TxRx Only
- RFFamily/Standard: General ISM < 1GHz
- Protocol: -
- Modulation: FSK, OOK
- Frequency: 290MHz ~ 340MHz, 424MHz ~ 510MHz, 862MHz ~ 1.02GHz
- DataRate(Max): 22.6kbps
- Power-Output: 7.25dBm
- Sensitivity: -106.5dBm
- MemorySize: -
- SerialInterfaces: SPI
- GPIO: -
- Voltage-Supply: 2.1V ~ 3.6V
- Current-Receiving: 10.3mA ~ 24mA
- Current-Transmitting: 6.1mA ~ 13.5mA
- OperatingTemperature: -20°C ~ 85°C
- MountingType: Surface Mount
- Package/Case: 32-VFQFN Exposed Pad
- MC33696FJAER2 NXP, IC RF TXRX ISM<1GHZ 32VFQFN, RF-IF and RFID~RF Transceiver ICs
MC33696FJAER2, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
