MC20XS4200FKR2 NXP IC PWR SWITCH N-CHAN 1:1 23PQFN
MC20XS4200FKR2 Images
MC20XS4200FKR2 Images
  • Manufacturer: NXP
  • Category: Integrated Circuits (ICs)~PMIC - Power Distribution Switches, Load Drivers SupplierDevicePackage: 23-PQFN (12x12)
  • Description: IC PWR SWITCH N-CHAN 1:1 23PQFN
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
MC20XS4200FKR2 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
MC20XS4200FKR2 Specifications:
  • MfrPart.: MC20XS4200FKR2
  • Mfr: NXP USA Inc.
  • Description: IC PWR SWITCH N-CHAN 1:1 23PQFN
  • Product Category: Integrated Circuits (ICs)~PMIC - Power Distribution Switches, Load Drivers
  • Package: Tape & Reel (TR)
  • Series: -
  • PartStatus: Last Time Buy
  • SwitchType: General Purpose
  • NumberofOutputs: 2
  • Ratio-Input:Output: 1:1
  • OutputConfiguration: High Side
  • OutputType: N-Channel
  • Interface: SPI
  • Voltage-Load: 8V ~ 36V
  • Voltage-Supply(Vcc/Vdd): 3V ~ 5.5V
  • Current-Output(Max): 3A
  • RdsOn(Typ): 20mOhm (Max)
  • InputType: -
  • Features: Internal PWM, Slew Rate Controlled, Watchdog Timer
  • FaultProtection: Current Limiting (Fixed), Open Load Detect, Over Temperature, UVLO
  • OperatingTemperature: -40°C ~ 125°C (TA)
  • MountingType: Surface Mount
  • SupplierDevicePackage: 23-PQFN (12x12)
  • MC20XS4200FKR2 NXP, IC PWR SWITCH N-CHAN 1:1 23PQFN, Integrated Circuits (ICs)~PMIC - Power Distribution Switches, Load Drivers
MC20XS4200FKR2, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
