MC15XS3400CPNAR2 Images
- Manufacturer: NXP
- Category: Integrated Circuits (ICs)~PMIC - Power Distribution Switches, Load Drivers SupplierDevicePackage: 24-PQFN (12x12)
- Description: IC PWR SWITCH N-CHAN 1:1 24PQFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MC15XS3400CPNAR2 Specifications:
- MfrPart.: MC15XS3400CPNAR2
- Mfr: NXP USA Inc.
- Description: IC PWR SWITCH N-CHAN 1:1 24PQFN
- Product Category: Integrated Circuits (ICs)~PMIC - Power Distribution Switches, Load Drivers
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- SwitchType: General Purpose
- NumberofOutputs: 4
- Ratio-Input:Output: 1:1
- OutputConfiguration: High Side
- OutputType: N-Channel
- Interface: SPI
- Voltage-Load: 6V ~ 20V
- Voltage-Supply(Vcc/Vdd): 3V ~ 5.5V
- Current-Output(Max): 6A
- RdsOn(Typ): 15mOhm
- InputType: -
- Features: Internal PWM, Slew Rate Controlled, Watchdog Timer
- FaultProtection: Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 24-PQFN (12x12)
- MC15XS3400CPNAR2 NXP, IC PWR SWITCH N-CHAN 1:1 24PQFN, Integrated Circuits (ICs)~PMIC - Power Distribution Switches, Load Drivers
