BAW156/ZLVL NXP DIODE ARRAY GEN PURP 75V SOT23
BAW156/ZLVL Images
BAW156/ZLVL Images
  • Manufacturer: NXP
  • Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays Package / Case: TO-236-3, SC-59, SOT-23-3
  • Description: DIODE ARRAY GEN PURP 75V SOT23
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
BAW156/ZLVL Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
BAW156/ZLVL Specifications:
  • Mfr Part: BAW156/ZLVL
  • Mfr: NXP USA Inc.
  • Description: DIODE ARRAY GEN PURP 75V SOT23
  • Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
  • Item12: Tape & Reel (TR)
  • Series: -
  • Part Status: Obsolete
  • Diode Configuration: 1 Pair Common Anode
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 75 V
  • Current - Average Rectified (Io) (per Diode): 160mA (DC)
  • Voltage - Forward (Vf) (Max) @ If: 1.25 V @ 150 mA
  • Speed: Small Signal =< 200mA (Io), Any Speed
  • Current - Reverse Leakage @ Vr: 5 nA @ 75 V
  • Operating Temperature - Junction: 150°C (Max)
  • Mounting Type: Surface Mount
  • Package / Case: TO-236-3, SC-59, SOT-23-3
  • BAW156/ZLVL NXP, DIODE ARRAY GEN PURP 75V SOT23, Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
BAW156/ZLVL, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
