BAV199/ZLVL Images
- Manufacturer: NXP
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays Package / Case: TO-236-3, SC-59, SOT-23-3
- Description: DIODE ARRAY GEN PURP 75V SOT23
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BAV199/ZLVL Specifications:
- Mfr Part: BAV199/ZLVL
- Mfr: NXP USA Inc.
- Description: DIODE ARRAY GEN PURP 75V SOT23
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
- Item12: Tape & Reel (TR)
- Series: -
- Part Status: Obsolete
- Diode Configuration: 1 Pair Series Connection
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 75 V
- Current - Average Rectified (Io) (per Diode): 160mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 1.25 V @ 150 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Current - Reverse Leakage @ Vr: 5 nA @ 75 V
- Operating Temperature - Junction: 150°C (Max)
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- BAV199/ZLVL NXP, DIODE ARRAY GEN PURP 75V SOT23, Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
BAV199/ZLVL, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
