BAT54,215 Images
- Manufacturer: NXP
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: TO-236-3, SC-59, SOT-23-3
- Description: NOW NEXPERIA BAT54 - RECTIFIER D
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BAT54,215 Specifications:
- Manufacturer Product Number: BAT54,215
- Mfr: NXP USA Inc.
- Detailed Description: NOW NEXPERIA BAT54 - RECTIFIER D
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Bulk
- Series: -
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 30 V
- Current - Average Rectified (Io): 200mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 800 mV @ 100 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr): 5 ns
- Current - Reverse Leakage @ Vr: 2 µA @ 25 V
- Capacitance @ Vr, F: 10pF @ 1V, 1MHz
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Operating Temperature - Junction: 150°C (Max)
- BAT54,215 NXP, NOW NEXPERIA BAT54 - RECTIFIER D, Discrete Semiconductor Products~Diodes - Rectifiers - Single
BAT54,215, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
