BAS40/ZLVL NXP DIODE SCHOTTKY 40V 120MA SOT23
BAS40/ZLVL Images
BAS40/ZLVL Images
  • Manufacturer: NXP
  • Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: TO-236-3, SC-59, SOT-23-3
  • Description: DIODE SCHOTTKY 40V 120MA SOT23
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
BAS40/ZLVL Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
BAS40/ZLVL Specifications:
  • Manufacturer Product Number: BAS40/ZLVL
  • Mfr: NXP USA Inc.
  • Detailed Description: DIODE SCHOTTKY 40V 120MA SOT23
  • Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
  • Package: Tape & Reel (TR)
  • Series: -
  • Part Status: Obsolete
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 40 V
  • Current - Average Rectified (Io): 120mA (DC)
  • Voltage - Forward (Vf) (Max) @ If: 1 V @ 40 mA
  • Speed: Small Signal =< 200mA (Io), Any Speed
  • Reverse Recovery Time (trr): -
  • Current - Reverse Leakage @ Vr: 10 µA @ 40 V
  • Capacitance @ Vr, F: 5pF @ 0V, 1MHz
  • Mounting Type: Surface Mount
  • Package / Case: TO-236-3, SC-59, SOT-23-3
  • Operating Temperature - Junction: 150°C (Max)
  • BAS40/ZLVL NXP, DIODE SCHOTTKY 40V 120MA SOT23, Discrete Semiconductor Products~Diodes - Rectifiers - Single
BAS40/ZLVL, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
