74LVC38AD,112 NXP IC GATE NAND OD 4CH 2-INP 14SO
74LVC38AD,112 Images
74LVC38AD,112 Images
74LVC38AD,112
  • Manufacturer: NXP
  • Category: Integrated Circuits (ICs)~Logic - Gates and Inverters SupplierDevicePackage: 14-SO
  • Description: IC GATE NAND OD 4CH 2-INP 14SO
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
74LVC38AD,112 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
74LVC38AD,112 Specifications:
  • MfrPart.: 74LVC38AD,112
  • Mfr: NXP USA Inc.
  • Description: IC GATE NAND OD 4CH 2-INP 14SO
  • Product Category: Integrated Circuits (ICs)~Logic - Gates and Inverters
  • Package: Tube
  • Series: 74LVC
  • PartStatus: Obsolete
  • LogicType: NAND Gate
  • NumberofCircuits: 4
  • NumberofInputs: 2
  • Features: Open Drain
  • Voltage-Supply: 1.2V ~ 5.5V
  • Current-Quiescent(Max): 40 µA
  • Current-OutputHighLow: -, 32mA
  • LogicLevel-Low: 0.7V ~ 0.8V
  • LogicLevel-High: 1.7V ~ 2V
  • MaxPropagationDelay@VMaxCL: 2.3ns @ 3.3V, 50pF
  • OperatingTemperature: -40°C ~ 125°C
  • MountingType: Surface Mount
  • SupplierDevicePackage: 14-SO
  • 74LVC38AD,112 NXP, IC GATE NAND OD 4CH 2-INP 14SO, Integrated Circuits (ICs)~Logic - Gates and Inverters
