74HCT132PW,112 NXP IC GATE NAND 4CH 2-INP 14TSSOP
74HCT132PW,112 Images
74HCT132PW,112 Images
  • Manufacturer: NXP
  • Category: Integrated Circuits (ICs)~Logic - Gates and Inverters SupplierDevicePackage: 14-TSSOP
  • Description: IC GATE NAND 4CH 2-INP 14TSSOP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
74HCT132PW,112 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
74HCT132PW,112 Specifications:
  • MfrPart.: 74HCT132PW,112
  • Mfr: NXP USA Inc.
  • Description: IC GATE NAND 4CH 2-INP 14TSSOP
  • Product Category: Integrated Circuits (ICs)~Logic - Gates and Inverters
  • Package: Bulk
  • Series: 74HCT
  • PartStatus: Active
  • LogicType: NAND Gate
  • NumberofCircuits: 4
  • NumberofInputs: 2
  • Features: Schmitt Trigger
  • Voltage-Supply: 4.5V ~ 5.5V
  • Current-Quiescent(Max): 2 µA
  • Current-OutputHighLow: 4mA, 4mA
  • LogicLevel-Low: 0.5V ~ 0.6V
  • LogicLevel-High: 1.9V ~ 2.1V
  • MaxPropagationDelay@VMaxCL: 33ns @ 4.5V, 50pF
  • OperatingTemperature: -40°C ~ 125°C
  • MountingType: Surface Mount
  • SupplierDevicePackage: 14-TSSOP
  • 74HCT132PW,112 NXP, IC GATE NAND 4CH 2-INP 14TSSOP, Integrated Circuits (ICs)~Logic - Gates and Inverters
74HCT132PW,112, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
