74HC4066DB,112 NXP 74HC4066DB - SPST, 4 FUNC, 1 CH
74HC4066DB,112 Images
74HC4066DB,112 Images
  • Manufacturer: NXP
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 14-SSOP (0.209, 5.30mm Width)
  • Description: 74HC4066DB - SPST, 4 FUNC, 1 CH
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
74HC4066DB,112 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
74HC4066DB,112 Specifications:
  • MfrPart.: 74HC4066DB,112
  • Mfr: NXP USA Inc.
  • Description: 74HC4066DB - SPST, 4 FUNC, 1 CH
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tube
  • Series: -
  • PartStatus: Active
  • SwitchCircuit: SPST - NO
  • Multiplexer/DemultiplexerCircuit: 1:1
  • NumberofCircuits: 4
  • On-StateResistance(Max): 95Ohm
  • Channel-to-ChannelMatching(ΔRon): 3Ohm
  • Voltage-SupplySingle(V+): 2V ~ 10V
  • Voltage-SupplyDual(V±): -
  • SwitchTime(TonToff)(Max): 30ns, 20ns
  • -3dbBandwidth: 200MHz
  • ChargeInjection: -
  • ChannelCapacitance(CS(off)CD(off)): 3.5pF
  • Current-Leakage(IS(off))(Max): 1µA
  • Crosstalk: -60dB @ 1MHz
  • OperatingTemperature: -40°C ~ 125°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 14-SSOP (0.209, 5.30mm Width)
  • 74HC4066DB,112 NXP, 74HC4066DB - SPST, 4 FUNC, 1 CH, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
74HC4066DB,112, NXP authentic parts in stock from NXP authorized distributors, order today, can ship immediately.
