74HC00BQ-Q100,115 Images
- Manufacturer: NXP
- Category: Integrated Circuits (ICs)~Logic - Gates and Inverters SupplierDevicePackage: 14-DHVQFN (2.5x3)
- Description: IC GATE NAND 4CH 2-INP 14DHVQFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
74HC00BQ-Q100,115 Specifications:
- MfrPart.: 74HC00BQ-Q100,115
- Mfr: NXP USA Inc.
- Description: IC GATE NAND 4CH 2-INP 14DHVQFN
- Product Category: Integrated Circuits (ICs)~Logic - Gates and Inverters
- Package: Bulk
- Series: Automotive, AEC-Q100, 74HC
- PartStatus: Active
- LogicType: NAND Gate
- NumberofCircuits: 4
- NumberofInputs: 2
- Features: -
- Voltage-Supply: 2V ~ 6V
- Current-Quiescent(Max): 40 µA
- Current-OutputHighLow: 5.2mA, 5.2mA
- LogicLevel-Low: 0.5V ~ 1.8V
- LogicLevel-High: 1.5V ~ 4.2V
- MaxPropagationDelay@VMaxCL: 7ns @ 6V, 50pF
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- SupplierDevicePackage: 14-DHVQFN (2.5x3)
- 74HC00BQ-Q100,115 NXP, IC GATE NAND 4CH 2-INP 14DHVQFN, Integrated Circuits (ICs)~Logic - Gates and Inverters
